Total 13 articles

  • CT-16K500UV100CoF Camera & PCIe3004 CoaXPress Over Fiber Frame Grabber

    The CT-16K500UV100CoF is a high-performance scientific camera with a back-illuminated/UV-enhanced 16K TDI line sensor, 500 kHz line rate, dual-array HDR, and TEC cooling. Using a 100 Gbps CoF fiber interface and GenICam standard, it enables high-speed, low-latency imaging. This document covers specifications, operating modes, test setup, and functional tests including ROI, trigger, TDI control, and temperature monitoring for semiconductor, FPD, and PCB inspection.

    넶3 2026-09-28

  • Open-source FPGA UDP Protocol Stack with Complete Test

    This article introduces an open‑source full‑hardware UDP Ethernet loopback project based on Xilinx KU5P FPGA. It supports 10G/25G/40G Ethernet rates. Vivado TCL scripts are provided for one‑click project reconstruction. It implements UDP packet loopback, suitable for high‑speed data acquisition, Ethernet acceleration and FPGA network teaching.

    넶14 2026-09-28

  • JetKU‑Based Test for HikRobot MV‑CH040 Camera

    This paper presents tests of the HikRobot MV‑CH040 area‑scan camera on the JetKU embedded platform. Four Camera‑Link modes (Base, Medium, Full, 80‑bit) are verified, and over 300 FPS can be achieved under the 80‑bit mode. It describes hardware wiring, ImgGrab setup, parameter configuration and practical operation notes.

    넶10 2026-09-22

  • Hamamatsu C15550-22UP Single-Photon Camera and PCIe1004 Frame Grabber

    The Hamamatsu C15550-22UP (ORCA-Quest 2) is a high-performance qCMOS scientific camera with 9.4MP resolution, 0.30 e⁻ ultra-low readout noise, and 85% peak quantum efficiency. It is ideal for light-sheet microscopy, single-molecule fluorescence, super-resolution microscopy, and quantum computing. Paired with the Xingce PCIe1004 four-channel CoaXPress V2.0 frame grabber, it delivers plug-and-play high-speed image acquisition with full functional testing support.

    넶129 2026-08-28
